6/04/2025

Does CG FC200 Work After Software Update Expired?

Problem:

CG FC200 does not connect with VW Simos PCR2.1 ECU. It does not read, does not write. The update is finished.

Software gave error “EF0A: Failed to get authorization code.”

fc200  Failed to get authorization code

Solution:

When the update is finished the online server are interrupted.
This tool is very good but always with live license. As all tools of quality. Same case is with KESS3 Original.

FC200 annual subscription is cheap, though, $200 per year.

All online features require the device to be within its active upgrade service period, such as checksum correction, IMMO OFF, DTC Off etc. Only reading/writing a few ECUs can be done offline.

FC200 will do checksum correction for PCR2.1, so it requires network connection.

6/03/2025

CG100X 1.6.8.0 Adds Ford Escort 2021- R7F701408 Dash

 CG100X programmer software update to V1.8.6.0 on June 3rd, 2025.

CG100X V1.8.6.0 Software
1. Added 22 models to dashboard.
2. Added 5 models to read-write.
The following models are added for dashboard.
Honda Motor NX400 S6J336C
Chenggong Zebra 24C16
DongFeng Dolica D12 9S12HZ128
DongFeng Fire Truck 9S12HY64
Toyota Granvia 2023- S6J3001LSJ
Toyota CROWNLUFANG 2023- S6J3001LSJ
Ford Escort 2021- R7F701408
FOTON TUNLAND V9 24C64
Geely EX3 2022- 24C16
JAC Dewa V8 24C08
JieFang DIAOCHE 9S12HZ256
qianjiang race Flash 300 PIC18F45K80
Nissan PATROL 24C16
Sanyang Maxsym 400 R5F10xxx
Lingong 85 Excavator 24C04
MAXUS Dana T1 24C16
WuLing RC-5 2020- S6J328C
Five signs(UFO) Aochi V3 24C16
XCMG Roller YT608D-XG 9S12HY48(Hour)
XCMG Roller 24C02(Hour)
Know beans Rainbow 2024- 24C16
ZhongTong Electric Bus 25256(25LC256)
The following models are added for dashboard read-write.
BYD AUTO BYD SONG PRO 2023- 24C16(Dashboard)+R7F701621(Dashboard)Read-Write
BYD AUTO BYD Song PLUS 2023- 24C16(Dashboard)+R7F701621(Dashboard)Read-Write
JINPENG JItu03 R5F10DLxxx(read write)
Leapmotor T03 CY15B064J(read write)
WANDA Bus CAT1025(read write)

6/02/2025

CG70 V1.1.8.0 Adds Benz BMS Unlock by CAN Mode

 CGDI CG70 airbag reset tool released new software V1.1.8.0 on June 2nd, 2025.


V1.1.8.0  NEW

(2025.05.30)

1.Added 194 additional airbag models.

2.Added Mercedes Benz BMS module unlocking function.

3.Some known problems fixed.


Unlock BMS module added the following models:

brand model chip

Mercedes W167 BMS(48V) 95M01

Mercedes W205 BMS(48V) 95M01

Mercedes W213 BMS(48V) 95M01

Mercedes W222 BMS(48V) 95M01


Airbag repair added the following models:

brand model chip

Buick 13594411 uPD70F3548

Chery 3606110-21 95080

Chery 407000402AA R7F701042

Chery A13-3606010DA 95160

Chery A13-3606010GA 95160

Chery A21-3606010 95080

Chery A21-3606010BA 95080

Chery A21-3606010FL 95160

Chery J26-3658010BA 95160

Chery J43-3658010 95320

Chery J52-3658010 95160

Chery J52-3658010BB 95160

Chery J69-3658010 95320

Chery P2406-10007 95080

Chery S21-3606010BC 95080

Chery T21-3658070BA 95320

Chery T21-3658070BB 95320

Chery T21-3658070FA 95320

Chery T21-3658070FB 95320

Chery T21-3658070FC 95320

Chevrolet 13518685 SPC56AP54

Chevrolet 13547591

Chevrolet 13578407

Citroen 9673654780 (609974000) 95320

Dacia 285559753R R7F701018

Dodge 68303636AA 95256

DongFeng 28556-2N012(J3858124) 95xxx

DongFeng 28556-2ZS00(J3858122) 95xxx

DongFeng 28556-2ZS01(J3858284) 95xxx

DongFeng 28556-2ZS02(J3858335) 95xxx

DongFeng 28556-2ZS03 95xxx

DongFeng 28556-2ZS70(J3858123) 95xxx

DongFeng 28556-2ZS71(J3858123) 95xxx

DongFeng 28556-2ZY1A(J3858338) 95xxx

DongFeng 28556-W6600 95xxx

DongFeng 28556-ZN012(J3858124) 95xxx

DongFeng 82MK-14150 95xxx

DongFeng J3858054(U410010J-B0100) 95xxx

DongFeng J3858055 95xxx

DongFeng J3858295(U410010-B0107) 95xxx

DongFeng J3858295(U410010J-B0107) 95xxx

DongFeng U410010J-B0101 95xxx

Ford 8M5T-14B321-AG 95160

GM 1003975 95080

GM 1005772 95080

GM 549640 95080

GM 90027091 95080

GM 96400534 95080

GM 96406711 95080

GM 96406712 95080

GM 96406713 95080

GM 96406714 95080

GM 96406715 95080

GM 96406716 95080

GM 96428774 95080

GM 96430711 95080

GM 96430712 95080

GM 96430713 95080

GM 96430714 95080

GM 96430715 95080

Great Wall 3658110A-G08 95080

Great Wall 3658110A-V08 95080

Great Wall 3658110XSZ08A 95320

Great Wall 3658120XPW03A XC2336A

Great Wall 3658160-K00 95080

Great Wall 3658160XK88XA(J3858206) 95320

Haima FA02-57-K30M1 95xxx

Haima FA11-57-K30M1 95xxx

Haima FA11-57-K30M2 95xxx

Haima HMCA-57-K30 95xxx

Haima HMCA-57-K30-M1A 95xxx

Haima HMEA-57-K30 95xxx

Haima HMFA-57-K30-M1A 95xxx

Haima HMFA-A57-30 95xxx

Haima J3858035 HMGA-57-K30 95xxx

Haima MA10-57-K30-M1 95xxx

Haima MA20-57-K30M1 95xxx

Haima SA18-57-K30 R7F701A033

Honda 77960-31X-W020-M2 TC23xx-32F

Honda 77960-31Y-H020-M2 TC23xx-32F

Honda 77960-3A0-Z220-M2 R7F701686

Honda 77960-3M0-P910-M1 TC23xx-32F

Honda 77960-T3L-Y021-M1 95640

Honda 77960-T3V-N011-M4 SPC560P50

Honda 77960-T5A-W411-M2 R5F2154

Honda 77960-T64-A920-M1 TC23xx-32F

Honda 77960-TVA-Q420-M4 SPC56AP54

Honda 77960-TZX-H810-M1 TC23xx-32F

Hyundai 95910-3Z000 95128

Hyundai 95910-AT210 95512

Hyundai 95910-BF300 TC23xx-32F

Hyundai 95910-DO500 TC23xx-32F

Hyundai 95910-G9600 TC23xx-32F

Hyundai 95910-G9660 TC23xx-32F

Hyundai 95910-G9880 TC23xx-32F

Hyundai 95910-GI310 TC23xx-32F

Hyundai 95910-HB000 TC23xx-32F

Hyundai 95910-L1750 TC23xx-32F

Hyundai 95910-L2AA0 95512

Hyundai 95910-L6200 TC23xx-32F

Hyundai 95910-P4220 TC23xx-32F

Hyundai 95910-P6200 TC23xx-32F

Hyundai 95910-R0130 TC23xx-32F

Hyundai 95910-R0510 TC23xx-32F

Infiniti 28556-4DW2A TC22xx-16F

Infiniti 98820-5CB0A 95128

Infiniti 98820-5VG1D TC22xx-16F

Infiniti 98820-6SX0B TC22xx-16F

KIA 95910-G6580 95512

KIA 95910-N9580 R7F701580

KIA 95910-P0320 R7F701580

KIA 95910-Q6800 R7F701019

Leopaard A133658010(J38580612) R7F701008

Leopaard A133658060(J38580624) R7F701008

Lexus 89170-0A081 R7F701A223

Lexus 89170-33S40 R7F701A223

Luxgen 285568U110 95320

Luxgen 28556SU100 95320

Luxgen 28556SU110 95320

Luxgen 28556SU120 95320

Mercedes A9079004105 A9079017900(0285015383) R7F701064

Mitsubishi 98820-W011P TC22xx-16F

Nissan 28556-2GR1A TC22xx-16F

Nissan 28556-2GV1A TC22xx-16F

Nissan 98820-2GN0B TC22xx-16F

Nissan 98820-2GV2B TC22xx-16F

Nissan 98820-2JC0B TC22xx-16F

Nissan 98820-4DW2B TC22xx-16F

Nissan 98820-5MT0A TC22xx-16F

Nissan 98820-6RU0A TC22xx-16F

Nissan 98820-7LG2A 95128

Nissan 98820-9PV2A TC22xx-16F

Nissan 98820-W016P TC22xx-16F

Peugeot 1366306080 610156000G 95320

Peugeot 9804502280 95320

Peugeot 9857895480 SPC56AP54

Peugeot 9861190580 SPC56AP54

Renault 285550749R R7F701042

Renault 285556057R TC22xx-16F

Renault 8200896814(402107B3) 95160

Roewe 11352920-01 TC22xx-16F

Roewe 11555725-11 TC22xx-16F

SsangYong 86250-36271 SPC560P50

Subaru 98221AL01B 95128

Subaru 98221SJ600 R7F701064

Subaru 98221VA010(Need RES 10K) H8SX1725

Suzuki 38910-59J10 95080

Suzuki 38910-59J10-000 95080

Suzuki 38910-59J11 95080

Suzuki 38910-59J11-000 95080

Suzuki 38910-59J12 95080

Suzuki 38910-59J12-000 95080

Suzuki 38910-59J30-000 95080

Suzuki 38910-59J40-000 95080

Suzuki 38910-59J41 95080

Suzuki 38910-59J41-000 95080

Suzuki 38910-59J70 95080

Suzuki 38910-59J70-000 95080

Suzuki 38910-59J71-000 95080

Suzuki 38910-84E21-000 95080

Suzuki 38910-86G00-000 95080

Suzuki 38910-86G02-000 95080

Suzuki 38910-86G03-000 95080

Suzuki 38910-86G12-000 95080

Toyota 89170-02T40 R7F7016443

Toyota 89170-0E600 R7F7016443

Toyota 89170-0E630 R7F7016443

Toyota 89170-26820 H8SX172x

Toyota 89170-30F10 R7F7016443

Toyota 89170-30G00 H8SX1797

Toyota 89170-50N30 R7F7016443

Toyota 89170-60511(Need RES 10K) H8SX172x

Toyota 89170-60J30 H8SX1797

Toyota 89170-60P40 R7F7016443

Toyota 89170-76830 R7F7016443

Toyota 89170-78130 R7F7016443

TRAUM 3658010001-A40 R7F701A033

TRAUM 3658010002-A40 R7F701A033

TRAUM 365801002-A40 R7F701A033

Trumpchi 8040003CMV0101 R7F701042


Airbag diag added the following models:

brand model chip

Daihatsu 89170-B2B50 0285012501(diag only) 95640

Daihatsu 89170-B5080 0285012586(diag only) 95640

Daihatsu 89170-B5090 0285012587(diag only) 95640

Dodge 68148914AB(diag only) 95128

Fiat 52219048(diag only) TC23xx-32F

Jeep 68675763AA(diag only) R7F701330

Nissan 98820-9PV4B(diag only)

Toyota 89170-BZ800(diag only) R7F701A313

Toyota 89170-BZ840(diag only) R7F701A383

VW 1EA959655FA VW40(diag only) TC23xx-32F

VW 1EA959655H VW40(diag only) TC23xx-32F

VW 3WA959655AB VW50(diag only) TC23xx-32F

VW 3WA959655P VW50(diag only) TC23xx-32F

VW 5QS959655D VW50(diag only) TC23xx-32F

5/29/2025

CGDI Wire vs Wireless vs Smart Remote Key

CGDI has also released a series of universal remote keys. How can we tell between these different types of keys? Here are some clues.



CGDI remote keys can be divided into 3 types:

Remote starts with C13– is the wired remote. Generating a brand-new wired remote will get 25 points.

Remote starts with C14- is the wireless remote. Generating a brand-new wireless remote will get 40 points.

Remote starts with C15- is the NXP smart remote. Generating a brand-new smart remote will get 60 points.

CGDI provides BMW, Ford, Mercedes-Benz, Porsche, Subaru, and Toyota types of smart remotes.



Points can be exchanged for tokens to clone ID48 96bit transponder CGDI K2 key tool.

90 points= 1 calculation (ID48 96bit).



NOTE:

CGDI remote keys can ONLY be generated by CGDI devices.

Buy 20 CG remotes, send id48 96bit tokens for 6 months (1 token per day). Buy 40 remotes, send 1 year of unlimited tokens.

CGDI Wire vs Wireless vs Smart Remote Key 1

CGDI Wire vs Wireless vs Smart Remote Key 2

CGDI Wire vs Wireless vs Smart Remote Key 3





5/28/2025

CG100X Great Wall Haval MB91F594BS Mileage Correction

Here we will demonstrate how to correct odometer of the new Great Wall Haval models. Taking a 2021 Haval H6 as an example, its instrument cluster is equipped with an MB91F594BS encrypted chip, and almost no devices can read the data from this encrypted chip.

CG100X Great Wall Haval MB91F594BS Mileage Correction 1

CG100X Great Wall Haval MB91F594BS Mileage Correction 2

with Fujitsu MB91F594BS microcontroller.



Tool used:

CG100X programmer



Instructions:

Record the original mileage.

Remove instrument cluster and disassemble.

Power on the instrument cluster according to the wiring diagram and give 12V power supply. Check if the dashboard is in good condition.

CG100X Great Wall Haval MB91F594BS Mileage Correction 3

Verify the original mileage—the initial reading is 212,528 km, which matches the actual mileage.

Customer desired mileage: 62,068km.

CG100X Great Wall Haval MB91F594BS Mileage Correction 4

In CG100X software, select Great Wall- Haval H6- MB91F594BS.

Device cannot read chip data directly so there is no wiring diagram for this cluster.

CG100X Great Wall Haval MB91F594BS Mileage Correction 5

Connect the cluster with CG100X programmer via the CAN adapter and cable as following:

CG100X Great Wall Haval MB91F594BS Mileage Correction 6

CG100X Great Wall Haval MB91F594BS Mileage Correction 7

Then read mileage data with CG100X software.

Ensure that the data read by the software matches the data displayed on the instrument cluster.

The device does not have an automatic mileage adjustment algorithm—contact CG100 technical support to manually modify the mileage data.

During the mileage correction process, the instrument cluster screen going blank is normal.

Once the adjustment is complete, power on the cluster to check the new mileage data.

CG100X Great Wall Haval MB91F594BS Mileage Correction 8

Install dashboard back to vehicle.

5/27/2025

CG100X V1.8.5.0 Adds Toyota S6J3001 Mileage Correction by CAN

CGDI CG100X programmer released new software version V1.8.5.0 on May 28th, 2025. The new version adds more Toyota S6J3001 mileage correction models by CAN.



CG100X previously supported some models for odometer correction by soldering (here is an example), but now it has been upgraded to cover more vehicle models and supports CAN mode for odometer adjustment.

CGDI CG100X new version V1.8.5.0 update details:
1. Added 1 chip to Programmer.
2. Added 25 models to dashboard.
3. Added 1 models to read-write.
The following chips are added for Programmer.
9S12ZVCA192
The following models are added for dashboard.
Toyota Super bully 2019- S6J3001 CAN
Toyota AVALONlion 2019- S6J3001 CAN
Toyota AVALON 2018- S6J3001 CAN
Toyota AVANZA 2023- S6J3001 CAN
Toyota CAMRY 2018- S6J3001 CAN
Toyota CHR/IZOA(Yize) 2018- S6J3001 CAN
Toyota COROLLA 2018- S6J3001 CAN
Toyota Corolla Cross 2021- S6J3001 CAN
Toyota CROWNLUFANG 2018- S6J3001 CAN
Toyota Granace 2019- S6J3001 CAN
Toyota Granvia S6J3001 CAN
Toyota Harrier 2016- S6J3001 CAN
Toyota HIACE 2019- S6J3001 CAN
Toyota Highlander 2018- S6J3001 CAN
Toyota Levin 2019- S6J3001 CAN
Toyota Levin 2019- S6J3001 CAN
Toyota RAIZE 2023- S6J3001 CAN
Toyota RAV4 Rongfang 2019- S6J3001 CAN
Toyota Sienna 2019- S6J3001 CAN
Toyota TACOMA 2018- S6J3001 CAN
Toyota Venza 2019- S6J3001 CAN
Toyota VIOS 2023- S6J3001 CAN
Toyota WILDLANER 2019- S6J3001 CAN
Toyota YARiS S6J3001 CAN
Toyota Yaris 2019- S6J3001 CAN
The following models are added for dashboard read-write.
Land Rover L8B2-10C784-AJ 9S12ZVCA19V(0N25N)(read write)



CAN mode requires the 35xx CAN adapter. The adapter is included in the package.

Check CAN mode connection diagram in the CG100X software.

CG100X V1.8.5.0 Adds Toyota S6J3001 Mileage Correction by CAN 1

CG100X V1.8.5.0 Adds Toyota S6J3001 Mileage Correction by CAN 2





5/25/2025

CG FC200 Adds DTC Off for Many ECUs

CG FC200 ecu programmer released new software version V1.2.9.0 on May 26th, 2025.

The new version adds DTC OFF function for various BMW, Mercedes, Hyundai, VAG, PSA, Toyota, Nissan, Renault ECUs.



CG FC200 new version V1.2.9.0 updating details:
1. Added DTC Off Function:
BMW-Bosch:EDC16C31, EDC16C35, EDC16CP35, EDC17C06, EDC17C41, EDC17C50, EDC17C56, EDC17CP02, EDC17CP09
Mercedes Benz-Delphi: CRD2.x, CRD3.x
Mercedes Benz Bosch: EDC16C32, EDC16CP31, DCU17PC42, EDC17C66, EDC17CP01, EDC17CP10
Volkswagen-Delphi: DCM6.2
Volkswagen-Bosch: EDC16U1, EDC16U31, EDC16U34, EDC16CP34, EDC17C46, EDC17C54, EDC17C64, EDC17C74, EDC17CP04, EDC17CP14, EDC17U01, EDC17U05
Volkswagen-Continental: PCR2.1, SIMOS8.1, SIMOS8.2, SIMOS8.3, SIMOS8.4、SIMOS8.5
Hyundai Kia-Bosch: EDC16C39, EDC17C08, EDC17C53, EDC17C57, EDC17CP14
Opel-GM: E78, E80, E83, E98
Opel-Bosch: EDC16C39, EDC17C11, EDC17C18, EDC17C19, EDC17C42, EDC17C59, EDC17C60, EDC17C84
Mazda-Denso: R2xx, RFxx, SH1x
Peugeot Citroen-Delphi: DCM 3.5, DCM 6.2A, DCM 7.1A
Peugeot Citroen-Bosch: EDC16C34, EDC17C10, EDC17C60
Renault-Bosch: EDC16C36, EDC17C11, DC17C42, EDC17C84
Subaru-Denso: KS/DT
Toyota-Bosch: EDC17C73, EDC17CP07
Toyota-Denso: Diesel Gen3
Land Rover-Bosch: EDC17CP11
Fiat-Bosch : EDC16C39, EDC17C49, EDC17C69
Ford-Delphi: DCM6.1
Ford-Bosch: EDC17C70, EDC17CP05
Honda-Bosch: EDC17_CP06
Iveco-Bosch: EDC16C39, EDC17C49, EDC17C69
Jeep-Bosch: EDC17C79
CNH-Bosch: EDC17C49

2. Added New ECU models:
Buick: MT60.1 MC9S12XEP768
Wuling: MT60.1 MC9S12XEP768
Shanxi Automobile: EDC17CV44
Great Wall: M7.9.7, M7.9.7.1, ME7.9.71, MT20U2 MC9S12XET256
Changhe: MT20U2 MC9S12XET256
Huatai: ME7.8.8, M7
Hafei Minyi: ME7.8.8, M7, TR40
Dongfeng: EDC17C81
Foton: TR40
3. Bug fixes:
1. Fixed the problem that some Volkswagen ME17.5.22/24/26 failed to modify VIN.
2. Fixed the problem that some SID209 failed to read password.

CG FC200 Adds DTC Off  1

CG FC200 Adds DTC Off  2



5/18/2025

CG FC200 Software Update to V1.2.8.0

CG FC200 new version V1.2.8.0 updating details:
1. Models with the "Three readiness monitors not ready" function added:
BMW: MSV90, MEVD17.2.2, MEVD17.2.8, MEVD17.2.H
Hyundai/Kia: SIM2K-240, SIM2K_341
2. Volkswagen DQ380/DQ381 TCU added the "Mileage Repair" function
3. Added Hyundai/Kia ECU/TCU:
SIM2K-250_ECU, SIM2K-250_TCU, SIM2K-260, SIM2K-140_ECU, SIM2K-140_TCU, SIM2K-141_ECU, SIM2K-141_TCU
4. Added Xiali DFO JH30 module read and write functions, "Modify VIN" and "Three readiness monitors not ready" functions
5. Added SAIC Maxus DFO TR20 module read and write function, "Modify VIN" and "Three readiness monitors not ready" functions
6. ECUs with new verification function: MD1CC878, DCM3.7AP
BUG fixes:
1. Optimize the "Three readiness monitors not ready" function of DCM7.1AP
2. Fix the problem that some BOSCH TC17xx ECUs prompt that the version is not supported
3. Fix the problem that CPEGP2.10.1 fails to verify PFlash
4. Optimize the checksums: DCM7.1AP, GM E37/E78/E83, PCR2.1, MT80, 9HP

cg fc200 v1.2.8.0



CG100X Software Update to V1.8.4.0

 CGDI CG100X new version V1.8.4.0 update details:
1. Added 4 models to dashboard.
2. Added 7 models to airbag.
3. Added 3 models to Body repair.
4. Added 10 models to read-write.
The following models are added for dashboard.
 Kawasaki Z400 93C66
 HaoJue DKS150 R5F10DPxxx
 HaoJue USR125 R5F10DPxx
 Geely Gleagle GC7 24LC04
The following models are added for airbag.
 BYD AUTO EM2E-3658100C Step Two SPC560P50L3
 Trumpchi 8040003ARD0500 SPC560P40L1
 Trumpchi  8040003ARD0501 SPC560P40L1
 Chery 407000194AB 681668900 XC2336A-72F
 Nissan 98820-6LK0B 95256
 WuLing  23764786 R7F701008
 Great Wall 3658120XKZ78A TC222-16F
The following models are added for Body repair.
 JinBei TR40 ST10F273M
 JinBei LEC4A ST10F273M
 JinBei STC 213 ST10F273M
The following models are added for dashboard read-write.
 Audi  4N0915105B MPC5644B(read write)
 BYD AUTO EM2E-3658100C Step One95128(read write)
 BYD AUTO 3668100-SY01 95128(read write)
 BYD AUTO EQEA-3658100D 95128(read write)
 Skyworth J38580763 C4060670BAA 95320(read write)
 DongFeng U400012360 95320(read write)
 Ford  Equator Sport 2022- R5F10DSKL(read write)
 Geely 6608100635 512013 R7F701330(encrypted)(read write)
 Chery  F16-3658010CL 25320(read write)
 Citroen ELV C4L 95040(read write)

CG100X Software Update to V1.8.4.0



CG100X Read and Write Benz W907 Airbag R7F7010643

How to read and write Mercedes Sprinter W907 airbag ECU with CG100X programmer.

CG100X has a solution for this airbag ecu. Only read and write, need to edit data manually and write to SRS to reset crash data.

Airbag module HW: A907 901 79 00

BOSCH Number: 0285015024

Processor: RENESAS R7F7010643 (RH850) eeprom 95128

CG100X Read and Write Benz W907 Airbag R7F7010643 1

CG100X Read and Write Benz W907 Airbag R7F7010643 2

Select Programmer function. Search R7F701064 mcu.

CG100X Read and Write Benz W907 Airbag R7F7010643 3

Check wiring diagram.

Connect CG100X with airbag module via Pro V2 adapter. Don’t forget to connect 12V power supply to CG100X.

CG100X Read and Write Benz W907 Airbag R7F7010643 4

CG100X Read and Write Benz W907 Airbag R7F7010643 5

Read and save Dflash.

CG100X Read and Write Benz W907 Airbag R7F7010643 6

Read and save PFLASH.

CG100X Read and Write Benz W907 Airbag R7F7010643 7

Read and save OPBT0 data.

CG100X Read and Write Benz W907 Airbag R7F7010643 8

Then read and save BOOT data.

CG100X Read and Write Benz W907 Airbag R7F7010643 9

Edit/modify srs eeprom dflash data by tuners or 3rd party.

Write modified airbag dflash data back to the SRS module.

CG100X Read and Write Benz W907 Airbag R7F7010643 10

CG100X Read and Write Benz W907 Airbag R7F7010643 11

CG100X Read and Write Benz W907 Airbag R7F7010643 12

Reset airbag module successfully.



Carprotool also does this airbag ecu.

pinout to CPT.

CPT-1 is RESET
CPT-2 is VCC
CPT-5 is RXD
CPT-6 is TXD
CPT-7 is FMLD0
CPT-8 is P10_8 pin on some devices its optional
CPT-9 is GND



OBDSTAR P50 does cover this airbag, but diagnostics only, cannot reset srs crash.
